In this article, I will discuss my recent experience replacing an older SOHO WAN router running OPNSense with a newer one.

Problem summary. I live and work in a remote area, which does not have the most reliable power and internet connections. I’ve addressed the intermittent power outages by installing a battery back-up system which covers the server cabinet and various other circuits in the house. I’ve addressed the intermittent network issues by deploying a multi-WAN router, which is what this article is about.

The WAN router also provides me with an extra NAT layer between my home/work network and the Internet, as you never know if you can trust ISP-provided routers. Additionally, it provides me and members of my team with OpenVPN access to resources on the network when we’re out and about, and much more besides.

The first router I bought was an Alix 2D3 (pictured below), which is based on AMD Geode LX800 with 256MB of RAM. It ran pfSense happily for the first few years, until one day earlier in 2019 when I went to upgrade it and found that pfSense stopped providing and supporting 32-bit builds. At this point, I switched to using OPNSense, and found that it did just as good a job as pfSense at all the things I needed it for, and allowed me to get some extra usage out of the old Alix router.

Towards the end of the 2019, I started having problems where the Alix-based unit would crash overnight and I’d have to reboot it almost daily each morning when starting work. I decided to look for a slightly more powerful and reliable unit, more appropriate to my networking requirements. For various reasons, I ended up choosing a ‘no name’ Chinese router, based on an Intel Celeron J3000 with 8GB of RAM, advertised as being compatible with pfSense/OPNSense, and would be rack-mountable so would fit better into my server rack next to my switch. I received it last week, and so this article covers how I went about replacing the Alix unit with it.

The first thing I did was to prepare a USB stick containing the latest distribution of OPNSense, and use it to deploy OPNSense to the unit’s 32GB SSD drive. This was fairly simple and painless, and on rebooting the unit was listening on IP address 192.168.1.1.

So, I went back to my laptop and configured a virtual IP on it, so that I could continue to configure it from there.

sudo ifconfig enp0s31f6:0 192.168.1.99/24

On the Alix, the NICs were labelled vr0, vr1 etc, but on the new unit they are labelled igb0, igb1 etc. so simply restoring the configuration in it’s entirety from the Alix unit wasn’t going to be trivial. Plus, the newer hardware had more ‘features’ I could make use of, such as hardware-level encryption for the OpenVPN traffic, so I wanted to take this opportunity to thoroughly review all the settings. In the end, I configured the main settings by hand, and used the ‘backup and restore’ facility of the OPNSense to restore specific chunks of the saved Alix configuration, before checking and updating them accordingly.

Once I was happy that the settings on the new unit closely matched the settings on the old unit, I took the new unit from the workshop, and installed it into the server cabinet. In doing so, I removed a redundant second Zyxel GS2210-24 managed switch I no longer use and reconnected all the devices to the first switch. This made room for the new router directly below the first switch.

At this point, to avoid conflicts and confusion, I disconnected the Alix router, connected up the new router and booted it up. The good news was that all the main (wired) devices in the office and around the house were working as normal. The bad news was that the wifi devices were not.

On my home network, I have various Ubiquiti wifi devices. I have three NanoStations for ‘back haul’ links running in ‘Bridge’ mode, with one mounted externally on the main house, and the other two on nearby houses which connect those buildings back to the main network. Then, at each site I have one or more Unifi AC access points, which provide wireless access to clients at those sites – typically mobile phones. As a side note, I also have a couple of Unifi G3 web cameras connected. All the Ubiquiti devices are powered via PoE, and to avoid running lots of ‘bricks’, I have them connected to a 5-port Ubiquiti ToughSwitch. For completeness, I should add that the Unifi wifi access points are managed by the excellent Unifi management software, which I run in Container Station on the QNAP NAS in the server cabinet. The key thing to note here is that the access points are configured so that client traffic is carried on VLAN 999.

Why? Because my kids and their friends like to install all sorts of stuff on their phones, and because I don’t have much faith in security with mobile phones, so I like to keep that traffic separate from my work-related traffic for some peace of mind.

So, the symptom of the problem was that wifi devices were associating fine with the access points, but failing to retrieve an IP address from the DHCP server on the OPNSense. So the first thing to check is that the VLAN configuration and DHCP server settings are as expected.

The VLAN was configured correctly.

And, the DHCP server was configured to run on the interface.

According to the DHCP logs and the leases table, the DHCP requests were being received and DHCP responses with IP addresses were being issued to connecting clients. I ran a packet dump on the WIFI interface on the router, and checked it with Wireshark, which confirmed this.

An equivalent packet dump running on my laptop suggested that it wasn’t seeing the DHCP offers.

In the end, I discovered that it wasn’t related to the OPNSense configuration at all. It was related to the Zyxel managed switch port that the ToughSwitch, and thus the Unifi access points and back-haul links were connected to for their PoE power. The ToughSwitch was connected to a port on the second switch before I removed it, and I connected it to what I thought was an equivalent port on the first switch. On closer inspection, the new port I had connected it to had previously been configured with static VLAN settings that were preventing it from transmitting traffic for VLAN 999, so the DHCP responses were effectively being black-holed.

The following shows the static port settings for VLAN 999 on the Zyxel switch.

I had the ToughSwitch connected to port 27. After moving it to port 25, wifi DHCP leases started being received by clients as expected.

After this, the next thing I needed to check was that remote users could connect back via OpenVPN. The WAN router is a ISP-provided ZTE router, which I have configured with a LAN IP address of 172.16.1.1/24. It connects directly to the OPNSense router, which is configured with a WAN IP address of 172.16.1.2/24. The ZTE router has the OPNSense WAN IP listed as a DMZ, so inbound UDP traffic for port 1194 is sent directly to the OPNSense, and thus the OpenVPN service. All that’s needed on the OPNSense, other than the OpenVPN server configuration itself, is a firewall rule to allow the UDP packets in. Nothing too complicated there.

The OpenVPN service is configured to use ‘SSL/TLS and User Auth’ for authentication, so I ensured my user password was set as expected, and issued myself a new TLS client certificate, as my previous one had expired. I tried a few test connections, and it worked fine.

As a side note, I recently started using the Hashicorp Vault as a CA for issuing internal TLS certificates, and it’s good. Combined with ‘cert-manager‘, it helps me simplify and automate a few local PKI tasks. It has Terraform integration which helps with general infrastructure secret management. Definitely worth looking into.

This one comes up quite regularly, so worthy of note. Whenever an application using Postgres changes or creates tables (i.e. Odoo module updates for example), those tables don’t seem to be accessible by the backups user on the next backup run. This is the SQL I use to work around it:

GRANT SELECT ON ALL TABLES IN SCHEMA public to backups;
GRANT SELECT ON ALL SEQUENCES IN SCHEMA public to backups;
ALTER DEFAULT PRIVILEGES IN SCHEMA public GRANT SELECT ON TABLES TO backups;
ALTER DEFAULT PRIVILEGES IN SCHEMA public GRANT SELECT ON SEQUENCES TO backups;

It’d be nice to find a way for the backups user to automatically get read permissions, but I’ve yet to figure that out. I understood that the above ALTER DEFAULT PRIVILEGES would cover it, but I seem to need to run it myself each time there is a change.

I run into a small stumbling block the other evening while working on my ‘site domain manager’ project (for want of a better name). This is essentially a REST API running in a daemon service that manages the mappings of domains to websites, and uses ‘agents’ to automate the configuration via API calls to the various services involved (domain registrars, DNS servers, WAF providers, SSL certs etc.)

The problem arose because the manager class I was writing to interact with kubernetes needed to manage certificates. The kubernetes python client library has a whole bunch of useful higher-level API and model classes for listing, creating, updating the main models I needed to manage, such as the ConfigMap, DaemonSet, Service and Ingress, but because the Certificate is part of the cert-manager package, it doesn’t have the equivalent higher-level methods I needed.

In the end, we solved it by using the lower-level call_api method, as follows:

        siteid = sitename.split(".")[0]
        rawyaml = """
apiVersion: certmanager.k8s.io/v1alpha1
kind: Certificate
metadata:
  name: {{siteid}}-cert
  namespace: {{namespace}}
spec:
  acme:
    config:
    - dns01:
        provider: route53
      domains:
      - {{mainhostname}}
  commonName: {{mainhostname}}
  dnsNames:
  - {{mainhostname}}
  issuerRef:
    kind: ClusterIssuer
    name: letsencrypt-production
  secretName: {{siteid}}-tls
"""
        rawyaml = rawyaml.replace("{{siteid}}", siteid)
        rawyaml = rawyaml.replace("{{namespace}}", self.namespace)
        rawyaml = rawyaml.replace("{{mainhostname}}", mainhostname)
        model = yaml.load(rawyaml, Loader=yaml.SafeLoader)
        model['spec']['acme']['config'][0]['domains'] = aliases
        model['spec']['dnsNames'] = aliases

        path_params = {}
        auth_settings = ['BearerToken']
        header_params = {
            "Content-Type": "application/json"
        }
        query_params = []

        # Fetch latest state of resource to apply changes to
        response = self.api_client.call_api(f"/apis/certmanager.k8s.io/v1alpha1/namespaces/{self.namespace}/certificates", 'GET',
            path_params,
            query_params,
            header_params,
            auth_settings=auth_settings,
        )
        r = json.loads(self.api_client.last_response.data)
        certs = {x['metadata']['name']:x for x in r['items']}

        # If it doesn't exist, create it...
        certid = f"{siteid}-cert"
        try:
            if certid not in certs.keys():
                _logger.info(f"Creating certificate '{certid}' with {len(aliases)} hostnames...")
                response = self.api_client.call_api(f"/apis/certmanager.k8s.io/v1alpha1/namespaces/{self.namespace}/certificates", 'POST',
                    path_params,
                    query_params,
                    header_params,
                    body=model,
                    auth_settings=auth_settings,
                )
            else:
                _logger.info(f"Updating certificate '{certid}' with {len(aliases)} hostnames...")
                # Transplant metadata to allow update to work
                model['metadata'] = certs[certid]['metadata']

                # Attempt to update...
                response = self.api_client.call_api(f"/apis/certmanager.k8s.io/v1alpha1/namespaces/{self.namespace}/certificates/{certid}", 'PUT',
                    path_params,
                    query_params,
                    header_params,
                    body=model,
                    auth_settings=auth_settings,
                )
        except Exception as e:
            _logger.exception(e)
            return str(e)

You can see this in context here.

One of our sites stopped sending it’s mail a few days ago. Unfortunately, the SMTP plugin used does not provide any debug logs of the SMTP connection, and it’s ‘test’ tool just says that it sent the mail successfully. The logs for the SMTP service provider suggest they haven’t seen the connection. I issue a new password and reconfigure, still the same symptoms.

So, I just want to do a simple check of the new SMTP creds. I also wanted to use a simple tool to avoid having to recall (Google) the magic SMTP protocol incantations and perform them via ‘telnet’ or whatever. The ‘ssmtp’ tool sprung to mind for some reason, so I figured I’d see how simple that would be to use in this case.

I fired up a disposable docker container to perform this in.

docker run --rm -ti alpine sh

Then, installed and configured ssmtp as follows:

apk -U add ssmtp
cat >/etc/ssmtp/ssmtp.conf <<EOF
Mailhub=smtp.mailserver.com:587
Hostname=mydomain.com
AuthUser=29a0ca06-ec73-488f-883e-f8bda2225a99
AuthPass=29a0ca06-ec73-488f-883e-f8bda2225a99
UseSTARTTLS=YES
EOF

Now I can send test mail like this:

echo "Test mail" | ssmtp -v you@yourdomain.com

The output will show the SMTP transaction, and ultimately whether or not the authentication was successful.

So, something I had to do recently was to set up monitoring for a couple of specific Windows processes, so that we get notification via a Discord channel if those processes are not running on various hosts.

Typically, you’d do this with something like NSClient++ but this was proving to be too problematic and time-consuming to get the client side configured and working correctly.

So, I decided to try a different approach to keep things quick and simple. However, things turned out to be neither quick nor simple. I’ll save the rant, needless to say I generally leave managing our Windows hosts to our Windows people. I haven’t used Windows since ’98. I typically steer clear, and I’m not even sure why I took this on, or why I’m writing this up. I hope it helps someone else, but I personally hope never to have to come back here!

My assessment of the requirement suggested that all that is really needed here is an endpoint the monitoring server can contact that would return ‘OK all is well’ or ‘ERROR your process isn’t running’ as text responses. I wanted to do this with tools already available on Windows if possible, without having to download and install any third-party agents or libraries. As far as I know, that pretty much means Powershell. So, I took a deep breathe and rolled up my sleeves…

Try {
    $listener = New-Object System.Net.HttpListener
    $listener.Prefixes.Add("http://+:8123/")
    $listener.Start()
} Catch {
    Write-Host "Failed to configure or start listener: $($_.exception.message)"
    Exit 1
}

while($listener.IsListening) {
	$listenerContext = $listener.GetContext()
	$process = $listenerContext.Request.Url.LocalPath -replace "/",""

    $running = Get-Process $process -ErrorAction SilentlyContinue

    if($running) {
	    $Content = [System.Text.Encoding]::UTF8.GetBytes("OK - $($process) is running")
    }
    else {
	    $Content = [System.Text.Encoding]::UTF8.GetBytes("ERROR - $($process) is not running")
    }

	$listenerContext.Response.ContentType = "text/plain"
	$listenerContext.Response.OutputStream.Write($Content, 0, $Content.Length)
	$listenerContext.Response.Close()

	#$listener.Stop()
}

That needs to go in a file somewhere, such as C:\Scripts\ProcessCheck.ps1.

Now, for security purposes, we need a user this script can run as. I created a user in our ActiveDirectory service called ‘processcheck’ for this purpose. This user must have ‘Log on as batch job’ rights, which can be setup as follows:

1. In the Control Panel, open Administrative Tools, then Local Security Policy.
2. Beneath Security Settings, open Local Policies, and highlight User Rights Assignment.
3. Locate Log on as a batch job. Open the properties and add the ‘processcheck’ user.
4. When finished, save your changes and close the Local Security Settings window.

This script will still fail if the user running it does not have permission to listen at the URL it registers to. To work around this, run a PowerShell window ‘As Administrator’ (or as a user with sufficient perms) and run:

netsh http add urlacl url=http://+:8123/ user=processcheck

Next, we need to ensure our monitoring servers can access our endpoint, but the rest of the world cannot. This is done by adding a new rule to the Windows Firewall. The main configuration for the new rule can be seen from the ‘General’ and ‘Ports and Protocols’ tabs…

Now, we need to ensure that this script is running in the background at all times. Typically, you’d do this by running it as a service, but as it’s Powershell, it doesn’t look like that’s simple (possible?) without using a third-party wrapper to provide an ‘.exe’ to interact with that has all the expected properties of a Windows service. Instead, we’re just going to tell Task Scheduler to run it as a recurring process. The theory here is that the script will remain running, and if it dies the scheduler will just restart it automatically within a minute or two.

To create the task, start ‘Task Scheduler’, then ‘Create Task’. The main settings that needed to be configured can be seen in the ‘General’, ‘Actions’ and ‘Settings’ tabs…

A simple browser-based check on the Windows machine itself confirms that the endpoint is working locally:

Now we should be able to check this using curl from our monitoring servers.

# curl http://host1.ournetwork.lan:8123/iexplore
ERROR - iexplore is not running

So, on to the monitoring server side of things. I will assume you’re using Nagios or a derivative. We use Icinga2, so I’ll give examples using their configuration scheme.

If you’re feeling lazy at this point, you could just configure a basic check_http ensuring the response contains ‘OK’. However, that doesn’t make for a very meaningful error message when the process is not found or an error occurs.

So, best to add a custom check_process command that will make the HTTP call to the endpoint and act on the ‘OK’ or ‘ERROR’ response, or set the service to ‘UNKNOWN’ if it gets an unexpected outcome.

#!/usr/bin/env python3

"""
    Nagios plugin to check status of a process on a remote Windows server
    via a custom URL.
"""

from optparse import OptionParser
import sys
import requests

pluginver = '0.1'

# Parse commandline options:
parser = OptionParser(usage="%prog -h <host_and_port> [ -h ]",version="%prog " + pluginver)
parser.add_option("-H", "--host",
    action="store", type="string", dest="host", help="Host and port")
parser.add_option("-p", "--process",
    action="store", type="string", dest="process", help="Process name")
(options, args) = parser.parse_args()


def main():
    # Check commandline options
    if not options.host:
        print("UNKNOWN: Missing host value (e.g. 'yourhost1.yournetwork.lan:8123').")
        sys.exit(3)
    if not options.process:
        print("UNKNOWN: Missing process name (e.g. 'iexplore').")
        sys.exit(3)

    # Fetch status message
    r = requests.get("http://{}/{}".format(options.host, options.process))
    if r.status_code != 200:
        print("UNKNOWN: Endpoint returned unexpected HTTP status " + str(r.status_code))
        print(r.text)
        sys.exit(3)

    # Parse first line of status message
    l = r.content.decode("utf-8").split('\n')[0]
    if l[0:2] != "OK":
        print(l)
        sys.exit(1)
    else:
        print(l)
        sys.exit(0)

if __name__ == '__main__':
    main()

For the purposes of this blog article, I’ll assume the script has been installed in /etc/icinga2/scripts/check_windows_processand that we are checking hosts for the presence of a running iexplore.exe process. Also, in this case, I am using Icinga2, so you may need to adapt this to your monitoring system.

I’ll start with the command definition:

object CheckCommand "windows-process" {
  import "ipv4-or-ipv6"

  #command = [ PluginDir + "/check_windows_process" ]
  command = [ "/etc/icinga2/scripts/check_windows_process" ]

  arguments = {
    "-H" = {
      value = "$host_address$"
      description = "Hostname (and port) to check (i.e. 'myhost1:8123')"
    }
    "-p" = {
      value = "$process_name$"
      description = "Name of process to check for (i.e. 'iexplore')"
    }
  }

  vars.host_address = "$address$:8123"
  vars.process_name = false
}

Then, a template that can be used by the service definitions:

template Service "application-scheduler" {
    check_command = "windows-process"
    vars.process_name = "MyScheduler2"
    vars.disable_sms_alerts = true
}

You’ll have to fill in the rest according to your specific scenario and needs, but otherwise I hope you find this article useful.

There are several ways to extract the logs from a Kubernetes Nginx Ingress deployment into an ElasticSearch instance. One way I found was to use Elastic Filebeats, but I couldn’t find any really good examples of how to apply that to our cluster, and I felt it would clutter up the proxy servers with more containers they may not necessarily need.

Instead, I chose to use nginx’s syslog facility, which is a little more lightweight, and serves our purposes for now.

Essentially, in this post I will configure syslog access and error logging on the K8S nginx ingress deployment, and have that send access logs via syslog UDP packets to a NodeRED flow which passes them through to ElasticSearch.

I’ve chosen to use a NodeRED to translate the syslog packets for consumption by ElasticSearch as it allows me a lot more flexibility, but you could probably also use the syslog input plugin for Logstash if it’s more suitable for you.

This is just a high-level overview to keep it brief. I do not try to cover the setup or configuration of the components used (i.e. the K8S manifests etc.)

Pre-requisites

We’ll assume that you have ElasticSearch running somewhere, and that it is accessible via the hostname ‘elasticsearch’, and we can post entries to it via HTTP port 9200. We’ll also assume you have configured Kibana, for querying the ElasticSearch indexes.

We’ll assume that you have a NodeRED instance or container running in close proximity to the ElasticSearch instance or container, and that it is configured to listen to UDP port 1514, using the hostname ‘nodered’. In my scenario, it’s another deployment in the same K8S namespace, on the same host node. For the real setup I prefer to use internal IP addresses rather than a hostname, as if the hostname lookup fails nginx ingress can fail to start up, which is not a good thing to happen to production clusters when you least expect it.

We’ll assume you have a Kubernetes cluster running Nginx Ingress, and that it refers to a ConfigMap called ‘nginx-configuration’.

Nginx to NodeRED

First, update the ConfigMap to direct the access logs via syslog…

apiVersion: v1
kind: ConfigMap
metadata:
  name: nginx-configuration
  namespace: ingress-nginx
data:
  enable-syslog: "true"
  log-format-escape-json: "true"
  log-format-upstream: '{ "time": "$time_iso8601", "remote_addr": "$proxy_protocol_addr","x-forward-for":
    "$proxy_add_x_forwarded_for", "request_id": "$req_id", "remote_user":"$remote_user",
    "bytes_sent": $bytes_sent, "request_time": $request_time, "status":$status, "vhost":
    "$host", "request_proto": "$server_protocol", "path": "$uri","request_query":
    "$args", "request_length": $request_length, "duration": $request_time,"method":
    "$request_method", "http_referrer": "$http_referer", "http_user_agent":"$http_user_agent"
    }'
  syslog-host: nodered
  syslog-port: "1514"

To check that changes have been applied, I tend to get a shell on one containers and grep log_format /etc/nginx/nginx.conf.

If that shows the JSON log format, the sites are still working, and there are no significant errors/warnings in the container logs for the nginx containers, then we can move on.

NodeRED to ElasticSearch

Now, on the NodeRED instance, you need to import a new flow…

https://gist.github.com/rossigee/6510ca9226c31bb021d40dcf72855101

This will look a bit like this…

If you enable the toggle on the poorly-named ‘msg.payload’ node, you should start to see the flow of entries in the debug panel on the right.

If you do not see any activity in the debug logs, and you are sure your proxies are receiving hits, you should check that the syslog packets are being transmit correctly between the nginx proxy hosts and transported correctly to the NodeRED flow correctly. You can check for transmission errors in the nginx proxy logs and you can use tcpdump/wireshark to confirm/deny the presence of UDP port 1514 traffic between the two.

Elasticsearch and Kibana

So, if all is going well, ElasticSearch is now gathering a proxylogs index containing all the latest nginx ingress access logs. You just need to tell Kibana about that index. Go to ‘Management > Index Patterns’ in the Kibana UI, then select the proxylogsindex.

Then, in the ‘Dashboard’, you should be able to start drilling down into the logs gathered so far.

Monitoring

Additionally, the NodeRED flow above incorporates a simple health check designed to be monitored by our Prometheus servers. If the ElasticSearch doesn’t return a success response, it increments a ‘dropped entry’ counter, which it presents in Prometheus scrape format at the /web-proxy-logs/metrics endpoint. Prometheus can then raise an alert if that goes above zero for any significant amount of time. You may not need this and can remove that functionality from the flow if it’s not of use to you.

Alerting

Of course, once your live access logs are being fed into ES you can start to consider setting up alerts to notify you of undesirable conditions, such as excessive 50x status codes, excessive login attempts, page load times etc. There are lots of things you might like to be alerted about and several mechanisms for doing this. Hopefully I will have more time to look into ElasticSearch’s own Alerting solution and maybe write a future blog post about that.

However, for the purposes of this post I’ll demonstrate yet another use case for NodeRED. It really is an incredibly flexible tool, and worthy of a place in any sysadmin’s toolkit. In this case, I added a simple flow to check the ES logs every two minutes and let me know via Discord whether there were any 50x status codes since the last run.

https://gist.github.com/rossigee/3ec5db7a68660474dfa96c5e04bb3696

Security

It is worth protecting the UDP port from public access. You should create a firewall rule or NetworkPolicy to ensure UDP packets from the proxy host IPs to port 1514 are accepted, and others rejected.

So, you have an LDAP server running happily on port 636 but one of your client applications doesn't seem to be happy with the SSL connection for whatever reason. You need an intermediary container to handle the SSL connection to the LDAP server on port 636, presenting it to the local application on port 389.

First, we write a Dockerfile that will describe a container that runs up an haproxy daemon.

FROM alpine:latest
RUN apk -U add haproxy
COPY haproxy.cfg /etc/haproxy/haproxy.cfg
EXPOSE 389
CMD ["/usr/sbin/haproxy", "-db", "-f", "/etc/haproxy/haproxy.cfg"]

Now, we just need to provide the haproxy configuration:

frontend main
    bind *:389
    default_backend ldapserver

backend ldapserver
    server static ldap.yourdomain.com:636 ssl verify none

Now, run it up to test it:

docker build -t ldap-proxy .
docker run -d --rm -p 389:389 ldap-proxy
ldapsearch -W -x -H ldap://localhost
